Southwest Medical
Trotter Mobility Rehab Stroller Chair
Images
Fire Engine Red
Some images may display non-standard options.Part Number: TR-xx-00-xx
Retail Price:
Price: $999.00 Ea
DESCRIPTION
The Trotter is a lightweight portable positioning chair that provides transport solutions for parents and children. A wide range of options provide custom positioning for your individual needs and its simple adjustments allow the Trotter to grow with your child.
Lightweight folding frame with closure strap that holds the chair shut when folded. Black machine washable fabric. Crash tested for transit. The Trotter has passed a dynamic crash test done with a 130lbs. front-facing occupant tested at 30 mph.
Adjustable seat angle 5 and 22. Adjustable back angle 85, 90 and 95. 8" front casters and 10" rear wheels with toggle lock. Adjustable seat depth. Positioning pelvic belt and five point "H" harness with padded strap covers. The reversible padded strap covers increase comfort and one side of cover is imitation lamb's wool and the other is velour. Swing-away footrest are independently adjustable and removable.
SPECIFICATION
| Model: | TR-1200 | TR-1400 | TR-1600 | TR-1800 |
| Weight Capacity | 75 lb | 100 lb | 170 lb | 250 lb |
| Weight Capacity for Transit | 75 lb | 100 lb | 165 lb | 165 lb |
| Back Height | 24" | 24" | 24" | 24" |
| Seat Depth (add 3" with seat rail extension) | 9"-13" | 10" - 14" | 11"-15" | 12"-16" |
| Seat-to-Back Angle | 80º-95º | 80º-95º | 80º-95º | 80º-95º |
| Seat Angle | 20º | 20º | 20º | 20º |
| Seat Width | 12" | 14" | 16" | 18" |
| Seat-to-Footplate Height (leg length) | 4"-20" | 4"-20" | 4"-20" | 4"-20" |
| Seat-to-Floor Height at 90º (rear/front) | 19"/22" | 19"/22" | 19"/22" | 19"/22" |
| Push Handle Height | 41.5" | 41.5" | 41.5" | 41.5" |
| Folded Height | 16" | 16.5" | 17" | 17.5" |
| Overall/Folded Length | 45" | 45" | 45" | 45" |
| Overall Width (outside rear wheels) | 20.5" | 22.5" | 24.5" | 26.5" |
| Product Weight | 33 lb | 34 lb | 35 lb | 36 lb |
